Frequency Synthesizer

MPN: DL310V002SX-88 PTS DL310V002SX-88 Frequency Synthesizer DUAL CHANNEL .1-310 MHz D310 Number of channels2 fully independent output channels FrequencyRange:0.100 000 0 to 309.999 999 9 MHz Resolution:0.1 Hz Accuracy:same as frequency standard Control:remote by TTL-level parallel entry BCD or GPIB(optional) Switching Time(to within 0.1 radian at new frequency) 100 MHz-10 MHz digits:20 seconds 1 MHz digit:5 seconds 100 KHz-0.1 Hz digits:1 second transient, 2 second delay Phase-Continuous100 KHz through 0.1 Hz digitsSwitching Range(~1 MHz bandwidth) OutputLevel:+3 to +13 dBm (1V max, 50 ) Flatness: 0.5 dB Impedance:50 Control:preset and remote by analog voltage Spurious (at full power output, +13 dBm)OutputsDiscrete:-70 dBc Harmonics:-30 dBc at full output (-40 dBc at lower levels) Phase Noise:-63 dBc (0.5 Hz to 15 KHz) including effects of internal standard (1Hz):100 Hz/ -105 dBc, 1 KHz/ -115 dBc, 10 KHz/ -123dBc, 100 KHz/ -127 dBc Noise Floor:- 135 dBc/Hz FrequencyInternal:OCXOorTCXOStandard 3x10-9/day1x10-8/day 1x10-8/0-50 C 1x10-6/0-50 C 1x10-6/year2x10-6/year External:10.000 MHz, 0.4-2.0 Vrms into 300 ; 5.000 MHz, 0.5-2.0 Vrms into 300 Aux. Output:10.000 MHz, 0.4 Vrms into 50 (Note: internal or external standard required for operation) GeneralOperating Ambient:0 - 50 C, 95% R.H Power:110 - 125V, 50 - 400 Hz, 75W (100, 220, 240V optional) Dimensions:19 x 5.25 x 17.5 inches (relay rack or bench cabinet) Weight:40 lbs. Optional Phase Rotation:0-360 in 0.225 steps two fully independent channels, each covering 0.1-310 MHz +3 to +13 dBm output low phase noise fast switching, 3-20 s fully programmable, BCD or GPIB DDS standard with phase-continuous switching low power consumption, high reliability Tested and working as it should. Buy with confidence. All of our items have a 30 Day money back guarantee! Customer satisfaction is of utmost importance. H52 Frequently Asked Questions We believe the smoother buying experience is, the happier the customer is! Therefore, we have come up with the following frequently asked questions to help better understand the process. First and foremost, if you have a problem with your order please contact us FIRST without involving by going to your purchases page and using the contact seller link. Most problems will be resolved with no cost to the buyer without involving. Payment We accept PayPal payments from U.S. and International PayPal accounts. Payment is expected within 2 days of your order, otherwise an Unpaid Item Case will be opened. We are unable to change shipping addresses on any orders after payment has been sent. We are unable to cancel or make changes to any orders after payment has been sent. We are unable to add more items to any orders that have already been paid. We are unable to substitute different sizes or colors. All available sizes and colors can be found by going to our store. How do I get insurance? If you would like insurance to be added to shipping you must message me the dollar amount (total declared value of item) of insurance you would like to be added to shipping. I will then send you a new invoice. Depending on the shipping purchased, some carriers already include insurance up to a certain dollar amount. If we are not informed of insurance changes, we will ship item without any insurance purchased. Do You Combine Shipping? Yes, we gladly combine shipping at a combined / reduced rate in most cases. VERY IMPORTANT: Please contact us BEFORE you pay to give us a chance to revise your invoice. We do NOT issue partial refunds for shipping fees already paid. How Much Does it Cost to Ship? When Will You Ship My Stuff? Will I Receive a Tracking Number?
